Survey #1 - Solar Site Survey

Form Instructions

In the performance of this site assessment, always wear appropriate PPE in compliance with your state regulations and your organization’s safety guidelines. This includes gloves, eye protection, fall protection, and electrical safety guidelines.
⚠️ If a system is energized and indicates a ground fault, the racking may also be electrically energized and pose a shock hazard.
Complete all sections of the form. If a section is not applicable, mark it as N/A.
Take photos of key components and attach them to the form when required.
Be objective and factual in your observations.
Report on things not found as well as those found. Do not leave a question in the report about the existence of a particular condition.

1) Homeowner / Project Info

Homeowner Name Address Contact Phone Number Assessment Date Service Provider Technician Name Assigned Technician Email Assigned RMA or Case Number

Project Type

Rooftop Groundmount

System Type

PV only PV + BESS

Structure Type

Manufactured Single family Multifamily / Duplex Master metered

2) Scope of Work

Full Site Health Assessment Pre-PTO Workout Post-PTO O&M

3) AHJ / Utility

AHJ Name Utility Name Special AHJ/Utility Requirements (if known)

4) Property Photos

Capture: front (address visible), left side, right side, back, pre-existing damage, unpermitted structures.

Property Photos (required)

5) AC Electrical Information

Main Service Panel Location Pole location relative to house (if pole-mounted) Cardinal direction (pole) Distance (pole to house) Utility Entrance Main Service Panel Busbar Rating (A) Main Service Panel Breaker Size (A) Subpanel present? Renewable Meter Adapter? Subpanel Busbar Rating (A) Subpanel Breaker Size (A) AC Disconnect present? AC/DC Disconnect present? Production Meter present? Production Meter Manufacturer Production Meter Serial Number DAS / Monitoring equipment model and serial number Complies with AHJ equipment clearances? CTs present?

6) AC Electrical Photos

Include: disconnects, main/sub panels, breakers close-up, grounding/UFER, bonds, meters/CTs, LEDs, clearances.

7) Inverter Electrical Equipment

Inverter Manufacturer Inverter Model Optimizer/Microinverter Manufacturer Optimizer/Microinverter Model Inverter Serial Number Multiple inverter models / second PV system? Inverter producing power? Error codes / details Monitoring present? Monitoring type Observations

Strings / MPPT

	MPPT 1	MPPT 2
# Strings
Modules/String

Equipment grounding conductor present (EGC)?

8) Inverter Photos

Include: inverter exterior/interior, AC J-box, solar AC panel, conduit runs, clearances, labels, screen captures, optimizer/microinverter serial areas.

9) DC Rooftop Equipment

Module Manufacturer Module Model Wattage of panels (W) Multiple module models? Shading issues? Discoloration / damage / cracked glass? Snail trails? Cracked solar cells? Burn marks / hotspots? Roof grounding system complies? Combined strings? # Junction boxes Parallel connector type Water ingress in junction boxes? Wire type (Free Air) Wire type (In conduit) Loose conduit connections to J-box? Air-to-conduit transitions watertight? MC4 connector mismatched brands (list)

Array Table (1–5)

Array	Module Qty	Azimuth	Tilt	Shading	Soiling	Cable Mgmt	Rafter Sizes/Spans	Setbacks (C/NC)
1
2
3
4
5

10) DC Rooftop Photos

Include: J-boxes, arrays, module labels, conduits, racking, under-array wiring, MC4 samples, grounding.

11) Racking System

Ground mount system? Rooftop mounting style Racking Manufacturer Racking Model (Rail) Attachment Manufacturer Attachment Model Attachment spans Loose clamps/components? Metal flashing present? Array skirts present? Critter guards present? Ground rod at array? Array location complies with AHJ/Utility requirements?

12) Racking Photos

Include: racking/attachments, waterproofing, foundations for groundmounts.

13) Roof Information

Number of stories Roof Type

Composite Tile Metal Other

Other roof type (if applicable) Number of existing layers Structure type

Truss Single span rafter Supported by metal beams Supported by wood beams

Existing roof damage? If yes, describe Existing roof leaks? Estimated age of roof Rafter/beam spacing & size Complies with applicable fire setbacks?

14) Roof Photos

Include: penetrations/sealant, flashing/edges, wear/damage, ponding/debris, sagging areas, structural damage, interior signs of leaks.

15) Add-On Equipment

Existing EV charger? Quantity of EV chargers Existing batteries? Battery Manufacturer Battery Model Battery quantity Backup interface

16) Notes & Recommendations

Supervisor Notes Tech Notes Recommendations

PDF report will be generated on this device and downloaded automatically after you press “Submit”.
